Chicken Manure Organic Fertilizer Powder Packing Machine With
Electronic Scale
Introduction to fertilizer powder packing machine
Fertilizer powder packing equipment is a kind of machine that you
should assemble it in the end of fertilizer production line. In
fertilizer industry, its function is to pack the finished powdery
fertilizer into bags, which is usually applied to agricultural
fertilizer production plants.
Specifications of fertilizer powder packing machine
| Material | Powdered dry powder Ultra dry powder |
| Weighing Range(kg) | 20~50kg |
| Weighing Speed(bag/h) | ≥180 |
| Dividing value(g) | 20 |
| Level of accuracy | 0.2 |
| Power Supply | Three-phase four-wire: AC 380V 220V 50Hz (User self-sufficiency)
50Hz (User self-sufficiency) |
| Power Consumption | RV75 1.5kw RV50 0.75KW RV50 0.55KW |
| Gas Source | It is recommended to select an air compressor with a displacement
of 0.12 m3/min or more. |
| Gas Consumption | 0.4～0.6Mpa 1m3/h |
| Working Environment | 0～＋40℃ relative humidity≤90% |
| Sensor | ILGC-200KG-BA (KeLi Electric) |
| Computer Control Instrument | Intelligent computer controller YH3D YHD8 |
| Pneumatic Components | Yadeke, Taiwan |
| Dust Removal | Reserve dust outlet |
| Manufacturing Materials | Contact with the material is made of carbon steel, good fluidity,
wear resistance, corrosion resistance, easy to clean. |
| Feeding Method | Screw twister feed |
| Installation size(mm) | 2280(height)×1360(depth)×750(width) |
| Installation Method | The scale body is directly docked to the storage bin and does not
need to be added as an auxiliary steel frame. Occupied floor space
is small and easy to install. |
Working principle of fertilizer powder packing machine
1. First of all, when the conveyor transports the powdery materials
into the stock bin, through the weighing senor, weighing instrument
and weighing transmitter, PLC will automatically control the
packing machine to open the feed port until the weight reach the
ser value.
2. Then there needs a worker to put the bags under the unloading
port.
3. After powdery materials packed, the fertilizer powder packing
machine will automatically sew the fertilizer bags. In the end, the
conveyor will deliver the final fertilizer to the finished products
area.
Features of fertilizer powder packing machine
1. The fertilizer packing machine is easy to operate
2. The powder fertilizer packing machine is equipped with automatic
weighing, bagging and conveying system.
3. Through instrument control, this fertilizer packing machine can
weigh the materials precisely.
Advantages of fertilizer powder packing machine
1. The weighing system utilizes PLC touch screen controlling and is
designed according to the dustproof, waterproof and anti-corrosion
requirements.
2. Especially suitable for large doses of high speed and quantities
packaging for particle materials.
3. Simple operation, only two people are needed to complete the
whole packaging process.
Applications of fertilizer powder packing machine
This fertilizer powder packing machine is mainly used for automatic
quantitative packaging of powdery materials, such as organic
fertilizer, compound fertilizer, urea, nitrogen fertilizer,
phosphate fertilizer, potassium fertilizer, feed, washing powder
etc.
